ASDCL03Q0N9BT
Sunlord ASDCL03 Series ASDCL03Q0N9BT
Model
:
ASDCL03Q0N9BT
Catalogue
ASDCL03 Series Catalogue English (Download)
ASDCL03 Series Catalogue Chinese (Download)
Add to Basket
In your cart
Add to Basket
Contact us about this product
Description
Description
Manufacturer
Sunlord
Model
ASDCL03Q0N9BT
Inductors
Series
ASDCL03
Structure
Multilayer
Inductance
0.9nH
Inductance Tolerance
±0.1nH
Quality Q
14
L/Q Test Freq. (MHz)
500
SRF (MHz)
18000
DCR Max. (Ω)
0.07
Saturation Current (A) Isat
/
Heat Rating Current (A) Irms
0.75
Body Length (mm)
0.6
Body Width (mm)
0.3
Body Thick (mm)
0.3
Automotive
Yes
Min. Packaging (Pcs)
15000
